PM500

Power Module, 500kW

2N redundancy, integrated cooling, fire and security

Key Features:

• 500kW IT Load Capacity in full 2N redundant architecture for maximum uptime.

• Uptime Institute Tier III compliant design for mission-critical reliability.

• Prefabricated modular enclosure – deployable indoors or outdoors.

• Advanced Power Systems:

  • 2 × Vertiv APM2 UPS (600kVA each) with LFP batteries for 10-minute backup.

  • 2 × Cummins 1173kVA diesel generators for 24-hour runtime.

• High-efficiency cooling with Vertiv chilled water units in N+1 configuration.

• Comprehensive monitoring & control via Vertiv RDU system – remote and local access.

• Integrated security with cloud-managed cameras and two-factor access control.

• Fire protection using IG-541 gas suppression and MASD detection.

• Energy efficiency: UPS operating at >95% efficiency in double conversion mode.

• Built to Australian Standards and PSPF security requirements.
